Technical Women

047
Figure 1. Jean Sammet

"From A Soon-To-Be Ghost Town" by Fruit Bats

Till My Fingers Bleed by Haider Atta

Today

  • Locating page state.

$ cat announce.txt

  • Midterm will cover everything through today.

  • Jinghao will lead a midterm review in recitation tomorrow.

  • No recitation Friday.

  • I’ll record a midterm review screencast so that we can continue Friday.

Midterm

  • 50 minutes, 50 points. Scaled to 15% of your final grade.

  • Same format as previous years:

    • 10 1-point multiple choice

    • 6 choose 4 5-point short answer

    • 2 choose 1 20-point long answer.

  • Same approach as the pre-term: assigned seats, seating chart distributed 1-hour before, etc. Please be on time. We will end promptly at 2:50PM.

  • There is no makeup exam. If you are not here and not in the hospital, you will receive a 0.

  • 2016 wrinkle:

    • most of the multiple choice will similar to previous years

    • at least 2_ of the short answer will be from previous years

    • one of the long answer may be from a previous year

ASST2/ASST3 Late Credit

  • ASST2:

    • You can still submit (25 point penalty)

    • You can request the solution set (50 point penalty). If you do so, you will automatically receive your original ASST2 score.

  • ASST3 deal:

    • ASST3 is broken into three 100-point parts due at two-week intervals, starting Friday.

    • Late submission for the first two checkpoints will result in 10 point deductions.

    • Late submission for the final checkpoint will result in no credit.

Locating Page State

  • Process: "Machine! Store to address 0x10000!"

  • MMU: "Where the heck is virtual address 0x10000 supposed to map to? Kernel…​help!"

  • (Exception.)

  • Kernel: Let’s see…​ where did I put that page table entry for 0x10000…​ just give me a minute…​ I know it’s around here somewhere…​ I really should be more organized!

What are the requirements for how we locate page information?

  • Speed: translation is a hot path and should be as efficient as possible.

  • Compactness: data structures we use should not take up too much physical memory.

Page Tables

The data structure used to quickly map a virtual page number to a page table entry is called a page table.

  • Each process has a separate page table.

  • Why? Virtual addresses are private to each process and translated differently for each.

Flat Page Tables

Approach: use one array to hold all page table entries for each process. Virtual page number is index into this array.

flatpagetable 1
flatpagetable 2
flatpagetable 3
flatpagetable 4
flatpagetable 5
flatpagetable 6
flatpagetable 7

Flat Page Tables

  • Approach: use one array to hold all page table entries for each process. Virtual page number is index into this array.

  • Speed: O(1). VPN is used directly as an index into the array.

  • Compactness: 4 MB per process that may have to be contiguous! Most is unused!

flatpagetable 7

Linked List Page Tables

  • Approach: list of PTEs for each process, searched on each translation.

linkedlistpagetable 1
linkedlistpagetable 2
linkedlistpagetable 3
linkedlistpagetable 4
linkedlistpagetable 5
linkedlistpagetable 6
linkedlistpagetable 7
linkedlistpagetable 8
linkedlistpagetable 9

Linked List Page Tables

Approach: list of PTEs for each process, searched on each translation.

  • Speed: O(n) for n valid virtual pages.

  • Compactness: 4 bytes * n for n valid virtual pages. All entries are used!

linkedlistpagetable 9

An Early ASST3 K.I.S.S.:

Don’t feel like you have to do something overly complicated for ASST3! First get it right, then optimize.

Multi-Level Page Tables

Approach: build a tree-like data structure mapping VPN to PTE. Break VPN into multiple parts, each used as an index at a separate level of the tree.

  • Example: with 4K pages VPN is 20 bits. Use top 10 bits as index into top-level page table, bottom 10 bits as index into second-level page table.

    • Each page table is 210 * 4 bytes = 4K. Convenient!

Multi-Level Page Tables

multilevelpagetable 1
multilevelpagetable 2
multilevelpagetable 3
multilevelpagetable 4
multilevelpagetable 5
multilevelpagetable 6

Multi-Level Page Tables

Build a tree-like data structure mapping VPN to PTE. Break VPN into multiple parts, each used as an index at a separate level of the tree.

  • Speed: O(c). Constant number of look ups per translation depending on tree depth.

  • Compactness: Depends on sparsity of address space, but better than flat and worse than linked list.

Out of Core

So far we have been talking about cases where processes are able to use the physical memory available on the machine.

But what happens when we run out?

swapping 1
swapping 2
swapping 3
swapping 4
swapping 5
swapping 6
swapping 7
swapping 8
swapping 9
swapping 10
swapping 11
swapping 12

Out of Core

When we run out, there are two options:

  1. Fail, and either don’t load the process (exec()), don’t create a new process (fork()), refuse to allocate more heap (sbrk()), or kill the process if it is trying to allocate more stack.

  2. Create more space, preserving the contents of memory for later use.

Virtually Sneaky

Virtual address translation gives the kernel the ability to remove memory from a process behind its back.

What are the requirements for doing this?

  • The last time the process used the virtual address, it behaved like memory.

  • The next time the process uses the virtual address, it behaves like memory.

  • In between, whatever data was stored at that address must be preserved.

Next Time

  • Swapping. How do we remove a page?

  • Page replacement algorithms. How do we choose a page to remove?

← →
